12CWQ10FN
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
- Category
- Schottky Rectifier
- Datasheet
- Not available
Product Spectation
| Parameter | Symbol | Value |
|---|---|---|
| Maximum Recurrent Peak Reverse Voltage | VRRM | 100V |
| Recurrent Voltage | Vr | 70V |
| Maximum Average Forward Rectified Current 3/8”lead length at Ta =55°C | If(av) | 12A |
| Peak Forward Surge Current 8.3ms single half sine-wave superimposed on rated load | IFSM | 110A |
| Maximum Forward Voltage at rated Forward Current and 25°C | Vf | 0.95V |
| Maximum DC Reverse Current Ta =25°C at rated DC blocking voltage | Ir | 1μA |
| Maximum DC blocking Voltage | VDC | - |
| Maximum RMS Voltage | VRMS | - |
